Handling Sets SCG-HSS
Suction rate from 270 l/min to 650 l/min
Handling set ready-to-connect for easy installation and commissioning
Very good sealing on strongly structured surfaces due to flexibly adjustable pin curtain
High suction capacity with minimum air consumption for low operating costs
Protection of sensitive workpieces by controlled discharge of electrostatic charges
Highest process reliability at high throughput due to handling true to position and layer
Design
Design
- Basic model made of non-anodized aluminum with integrated compressed air driven vacuum generation (1)
- Suitable for side mounting (2)
- Flexibly adjustable gripping surface through pins with pneumatic fixation (3)
- Exhaust duct for controlled conduction of the air sucked in (4)
- Compressed air connection for vacuum generation (suction) (5)
Technical Data
Technical Data
- Flow gripper including mounting set, pressure reduction valves and plug-in screw unions
- Suction rate: 270 l/min to 650 l/min
- Suction area: pin curtain with Ø 47 mm
- ESD compliant
