SET SCHRAUBE FED-SCHE M8x9010.07.13.00182Assembly set for connecting 2
interlocking pipe tooling components
| contains | SCHRAUBE |
| and | FED-SCHE |
| Thread G | M8 |
| Length L | 90 (mm) |
Part no.: 10.07.13.00168
Design Data
Design Data
| Attribute | Value |
|---|---|
| Connection 1 | SXT-CON-GB-F-D40 |
| Connection 2 | SXT-CON-GB-M-D40 |
| B | 35 mm |
| d | 40 mm |
| d1 | 40 mm |
| H | 66 mm |
| H2 | 66 mm |
| H3 | 25 mm |
| H4 | 25 mm |
| L | 97.8 mm |
| X1 | 50.8 mm |
Technical Data
Technical Data
| Attribute | Value |
|---|---|
| Weight | 256 g |
| Product family | SXT |
Documentation
Documentation
Spare parts
