Schmalz

  • PHASE-OUT ITEM

Vacuum Blocks VCBL-GL Generation 1

Height 81.5 mm and 93.5 mm

Very high holding forces on dry and wet glass

Highest dimensional accuracy for more precision in the production process

Completely free of marks thanks to sealing ring made of HT1 material and friction plate made of Elastodur

Low restoring force of the sealing lip prevents deformation of the workpiece

Design
  • Sealing ring (1) made of low-marking material for contamination-free fixing of the workpiece
  • Friction surface (2) made of wear resistant material for gentle clamping of wet, dry and thin glass
  • Robust housing (3) made of aluminum
  • Screw in push fitting accessories (4) for hose connection of the vacuum system
Technical Data
  • With two hose connections for flat table
  • Calibrated friction pad
  • Height: 81.5 mm and 93.5 mm
