| Dimension (LxW) | 160 x 160 |
| Length L | 160 (mm) |
| Width B | 160 (mm) |
| Height H | 25 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
Highest holding forces in wood applications thanks to optimized seals and friction pads
Highest dimensional accuracy for more precision in the production process
Wide range of products offers maximum flexibility and enables short set-up times
Different overall heights allow even complex lateral processing
Long service life and fast, cost-effective replacement of spare parts
Design
Design
- Friction pad (1) for absorption of lateral forces
- Robust main body (2) made of plastic
- Positioning insert (3) for various groove widths
- Inserts are easy to change so that the vacuum block can be used for different grid sizes
- Sealing frame (4)
Technical Data
Technical Data
- Vacuum system for grid tables
- Fixation via positioning inserts
- Integrated touch valve
Documentation
Documentation
The matching documentation for this product is available in this section.
| Documents | Language |
|---|---|
| English |
1 - 7 from 7 results
| Dimension (LxW) | 160 x 160 |
| Length L | 160 (mm) |
| Width B | 160 (mm) |
| Height H | 45 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
| Length L | 160 (mm) |
| Width B | 160 (mm) |
| Height H | 125 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
| Dimension (LxW) | 160 x 160 |
| Length L | 160 (mm) |
| Width B | 160 (mm) |
| Height H | 150 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6x7 |
| Additional function vacuum block | Touch valve |
| Dimension (LxW) | 160 x 96 |
| Length L | 160 (mm) |
| Width B | 80 (mm) |
| Height H | 25 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
| Dimension (LxW) | 160 x 96 |
| Length L | 160 (mm) |
| Width B | 96 (mm) |
| Height H | 45 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
| Length L | 160 (mm) |
| Width B | 96 (mm) |
| Height H | 125 (mm) |
| Grid | 30/50 |
| Recommended slot width x slot depth [mm] | 6,5/7,5 |
| Additional function vacuum block | Touch valve |
